Setting Up a Home Lab Logging Stack with Loki, Promtail, and Grafana on K3s

Whether you're a hobbyist delving into the depths of home networking and server management, or simply someone passionate about maintaining a robust home lab setup, having a reliable logging system is crucial. It not only aids in troubleshooting but also helps in optimizing the performance of your applications. This guide is tailored for home lab enthusiasts looking to deploy Loki for log aggregation, Promtail for log collection, and Grafana for visualizing and querying logs, all on a lightweight Kubernetes platform, K3s. Let's dive into setting up a streamlined logging stack that can offer deep insights into your home lab's workings.

Prerequisites

Before diving into the deployment process, ensure you have the following:

• A running K3s cluster
• kubectl configured to communicate with your K3s cluster
• Basic familiarity with Kubernetes concepts like Deployments, Services, and PersistentVolumeClaims

Step 1: Deploying Loki

Loki is designed to aggregate logs from various sources, making log queries fast and efficient. We start by deploying Loki to the cluster.

Loki Deployment

Create a file named loki-deployment.yaml and paste the following content:

---
apiVersion: v1
kind: ConfigMap
metadata:
  name: loki-configmap
data:
  local-config.yaml: |
    auth_enabled: false

    server:
      http_listen_port: 3100
      grpc_listen_port: 9096

    common:
      instance_addr: 127.0.0.1
      path_prefix: /tmp/loki
      storage:
        filesystem:
          chunks_directory: /tmp/loki/chunks
          rules_directory: /tmp/loki/rules
      replication_factor: 1
      ring:
        kvstore:
          store: inmemory

    query_range:
      results_cache:
        cache:
          embedded_cache:
            enabled: true
            max_size_mb: 100

    schema_config:
      configs:
        - from: 2020-10-24
          store: boltdb-shipper
          object_store: filesystem
          schema: v11
          index:
            prefix: index_
            period: 24h

    ruler:
      alertmanager_url: http://localhost:9093

    # By default, Loki will send anonymous, but uniquely-identifiable usage and configuration
    # analytics to Grafana Labs. These statistics are sent to https://stats.grafana.org/
    #
    # Statistics help us better understand how Loki is used, and they show us performance
    # levels for most users. This helps us prioritize features and documentation.
    # For more information on what's sent, look at
    # https://github.com/grafana/loki/blob/main/pkg/usagestats/stats.go
    # Refer to the buildReport method to see what goes into a report.
    #
    # If you would like to disable reporting, uncomment the following lines:
    #analytics:
    #  reporting_enabled: false
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: loki
spec:
  selector:
    matchLabels:
      app: loki
  replicas: 1
  template:
    metadata:
      labels:
        app: loki
    spec:
      containers:
        - name: loki
          image: grafana/loki:2.9.4
          args:
            - "-config.file=/etc/loki/local-config.yaml"
          ports:
            - containerPort: 3100
          volumeMounts:
            - name: loki-config
              mountPath: /etc/loki
              readOnly: true
      volumes:
        - name: loki-config
          configMap:
            name: loki-configmap
---
apiVersion: v1
kind: Service
metadata:
  name: loki
spec:
  selector:
    app: loki
  ports:
    - protocol: TCP
      port: 3100
      targetPort: 3100

Deploy Loki by running:

kubectl apply -f loki-deployment.yaml

Loki Service

To access Loki within your cluster, create a service by defining loki-service.yaml:

Apply it using:

kubectl apply -f loki-service.yaml

Step 2: Setting Up Promtail

Promtail is parses logs from your kubernetes nodes. We need to configure it so that is has access rights and so that it will push logs to loki.

Promtail Deployment

Define promtail-deployment.yaml with the following:

---
apiVersion: v1
kind: ConfigMap
metadata:
  name: promtail-configmap
data:
  promtail.yaml: |
    server:
      http_listen_port: 9080
      grpc_listen_port: 0

    clients:
    - url: http://loki:3100/loki/api/v1/push

    positions:
      filename: /tmp/positions.yaml
    target_config:
      sync_period: 10s
    scrape_configs:
    - job_name: pod-logs
      kubernetes_sd_configs:
        - role: pod
      pipeline_stages:
        - docker: {}
      relabel_configs:
        - source_labels:
            - __meta_kubernetes_pod_node_name
          target_label: __host__
        - action: labelmap
          regex: __meta_kubernetes_pod_label_(.+)
        - action: replace
          replacement: $1
          separator: /
          source_labels:
            - __meta_kubernetes_namespace
            - __meta_kubernetes_pod_name
          target_label: job
        - action: replace
          source_labels:
            - __meta_kubernetes_namespace
          target_label: namespace
        - action: replace
          source_labels:
            - __meta_kubernetes_pod_name
          target_label: pod
        - action: replace
          source_labels:
            - __meta_kubernetes_pod_container_name
          target_label: container
        - replacement: /var/log/pods/*$1/*.log
          separator: /
          source_labels:
            - __meta_kubernetes_pod_uid
            - __meta_kubernetes_pod_container_name
          target_label: __path__
---
apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: promtail-daemonset
spec:
  selector:
    matchLabels:
      name: promtail
  template:
    metadata:
      labels:
        name: promtail
    spec:
      serviceAccount: promtail-serviceaccount
      containers:
        - name: promtail-container
          image: grafana/promtail:2.9.4
          args:
            - -config.file=/etc/promtail/promtail.yaml
          env:
            - name: "HOSTNAME" # needed when using kubernetes_sd_configs
              valueFrom:
                fieldRef:
                  fieldPath: "spec.nodeName"
          volumeMounts:
            - name: logs
              mountPath: /var/log
            - name: promtail-config
              mountPath: /etc/promtail
            - mountPath: /var/lib/docker/containers
              name: varlibdockercontainers
              readOnly: true
      volumes:
        - name: logs
          hostPath:
            path: /var/log
        - name: varlibdockercontainers
          hostPath:
            path: /var/lib/docker/containers
        - name: promtail-config
          configMap:
            name: promtail-configmap
--- # Clusterrole.yaml
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: promtail-clusterrole
rules:
  - apiGroups: [""]
    resources:
      - nodes
      - services
      - pods
    verbs:
      - get
      - watch
      - list

--- # ServiceAccount.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
  name: promtail-serviceaccount

--- # Rolebinding.yaml
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: promtail-clusterrolebinding
subjects:
  - kind: ServiceAccount
    name: promtail-serviceaccount
    namespace: default
roleRef:
  kind: ClusterRole
  name: promtail-clusterrole
  apiGroup: rbac.authorization.k8s.io

Apply this deployment:

kubectl apply -f promtail-deployment.yaml

Step 3: Deploying Grafana

Grafana is your window to the data collected and aggregated by Loki and Promtail.

Grafana Deployment

Create grafana-deployment.yaml with:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: grafana-pvc
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 2Gi
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: grafana-datasources
data:
  ds.yaml: |
    apiVersion: 1
    datasources:
    - name: Loki
      type: loki
      access: proxy
      orgId: 1
      url: http://loki:3100
      basicAuth: false
      isDefault: true
      version: 1
      editable: false
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: grafana
spec:
  selector:
    matchLabels:
      app: grafana
  replicas: 1
  template:
    metadata:
      labels:
        app: grafana
    spec:
      containers:
        - name: grafana
          image: grafana/grafana:latest
          ports:
            - containerPort: 3000
          env:
            - name: GF_PATHS_PROVISIONING
              value: "/etc/grafana/provisioning"
            - name: GF_AUTH_ANONYMOUS_ENABLED
              value: "true"
            - name: GF_AUTH_ANONYMOUS_ORG_ROLE
              value: "Admin"
          volumeMounts:
            - name: grafana-provisioning
              mountPath: /etc/grafana/provisioning/datasources
              readOnly: true
            - mountPath: /var/lib/grafana
              name: grafana-storage
      volumes:
        - name: grafana-storage
          persistentVolumeClaim:
            claimName: grafana-pvc
        - name: grafana-provisioning
          configMap:
            name: grafana-datasources

And deploy it:

kubectl apply -f grafana-deployment.yaml

Setup Metal Lb

I'm using metal lb in this guide so that Grafana can use a local network IP.

apiVersion: metallb.io/v1beta1
kind: IPAddressPool
metadata:
  name: main-pool
  namespace: metallb-system
spec:
  addresses:
    - 192.168.1.229-192.168.1.245
  autoAssign: true
---
apiVersion: metallb.io/v1beta1
kind: L2Advertisement
metadata:
  name: main-ad
  namespace: metallb-system
spec:
  ipAddressPools:
    - main-pool

Grafana Service

The Grafana service I've put together below uses metal lb so that we can map it to a local network IP address. Use whatever IP address you want below.

To access Grafana, create a service with grafana-service.yaml:

apiVersion: v1
kind: Service
metadata:
  name: grafana-lb
spec:
  selector:
    app: grafana
  ports:
    - protocol: TCP
      port: 3000
      targetPort: 3000
  type: LoadBalancer
  loadBalancerIP: 192.168.1.242

Apply this to make Grafana accessible:

kubectl apply -f grafana-service.yaml

Accessing Grafana

Grafana is now accessible through by going to 192.168.1.242:3000 in your webbrowser. Use the admin account to log in (default password is admin), and configure Loki as a datasource using the Loki service's cluster IP.

Conclusion

Deploying Loki, Promtail, and Grafana on a K3s cluster provides a scalable and efficient logging solution for Kubernetes environments. By following the steps outlined in this guide, you'll have a powerful toolset at your disposal for observability and log management.

Remember to monitor your deployments and adjust resources as necessary to ensure optimal performance. Happy logging!
